Canyon Ridge® Modern

Faux Wood Modern Garage Doors

Insulated modern style garage doors with faux wood-look composite overlays.

Canyon Ridge® Modern garage doors combine the beautiful look of wood with contemporary design. Streamline the look of a traditional home or add a sophisticated touch to a modern or mid-century style exterior with these durable faux wood modern doors.

Overview

Clopay Canyon Ridge® Modern garage doors provide a wide range of door designs that perfectly complement contemporary homes. These doors are constructed with steel for strength and durability, and molded composite materials for beauty and realism. These doors feature:

  • 4-layer construction including durable, composite, steel, and Intellicore® insulation.
  • 2″ Intellicore® polyurethane insulation with a thermal break.
  • R-Value ranging from 6.3 to 20.4.
  • WINDCODE® door reinforcement product available for high wind load applications. (Click for details.)

Environmental Assurance

Clopay doors are compliant with environmental laws and regulations. Clopay doors do not contain HFCs. All Clopay doors are compliant with:

  • California SB 1013
  • Washington HB 1112 – Hydrofluorocarbon Greenhouse Gas Emissions
  • Canadian regulations amending the ozone-depleting substances and halocarbon alternatives regulations
  • New Jersey A-5583/S-3919 – Greenhouse Gas Bill

Design Options

Customize your Clopay® garage door with your preferred design, color, hardware and glazing options.

cr-modern-plank6-only
PLANK
cr-modern-plank6-cc-dark-single-rightside-short
PLANK – SHORT WINDOWS DOWN SIDE
cr-modern-plank6-cc-dark-single-sides-short
PLANK – SHORT WINDOWS DOWN BOTH SIDES
crm_6plank-allwindows
PLANK – ALL WINDOWS
cr-modern-plank6-cc-dark-single-rightside-long
PLANK – LONG WINDOWS DOWN SIDE
cr-modern-plank6-cc-dark-single-full-long
PLANK – LONG WINDOWS DOWN BOTH SIDES

cr-modern-metalinlay-cc-dark
METAL INLAY

cr-modern-fullview
FULL VIEW

↑ Back To Top


Specialty Glass Options

rain
RAIN*
FROSTED
FROSTED*
obscure
OBSCURE*

↑ Back To Top


Material Options

METAL (ALUMINUM) INLAY CLADDING

MetalCladding-Clear Cypress
Clear Cypress
Overlay-Clear Cypress
Clear Cypress
PlankCladding-Clear Cypress
Clear Cypress

METAL (ALUMINUM) INLAY CLADDING

MetalCladding-Mahogany
Mahogany
Overlay-Mahogany
Mahogany
PlankCladding-Mahogany
Mahogany

↑ Back To Top


Color Options

crm_walnut_finish_swatch_84

WALNUT FINISH

crm_dark_finish_swatch_84

DARK FINISH

crm_medium_finish_swatch_84

MEDIUM FINISH

crm_whitewash_finish_swatch_84

WHITE FINISH*

Color-Black

BLACK FINISH

Canyon Ridge Modern Slate Finish

SLATE FINISH

crm_primed_swatch_84

PRIMED

Black and White Finish available only on Mahogany cladding and overlays.

↑ Back To Top


Hardware Options

avante handle

Optional Aluminum Grip Handle

HANDLES

spade lift handles

SPADE LIFT HANDLES
(included)

HANDLES

Spade Step Plate

SPADE STEP PLATE

PLATES

↑ Back To Top


Construction

Clopay® Canyon Ridge® Modern garage doors are built with a strong base door and overlays. The faux wood-look composite overlays are low maintenance, durable and won’t rot, warp or crack.

canyon ridge limited edition construction cutaway
  • Plank design: Faux-wood doors with intellicore® polyurethane insulation. 20.4 R-value.
  • Metal Inlay design:Faux-wood doors with intellicore® polyurethane insulation. 18.4 R-value.
  • Full View design: Faux-wood doors with intellicore® polyurethane insulation. 6.3 R-value.
  • Replaceable vinyl bottom weather seal in rust free aluminum retainer helps protect against the elements.
  • High performance nylon ball bearing rollers help ensure smooth, long-lasting, quiet operation.
  • Heavy-duty 14 gauge steel hinges and brackets for smooth and worry-free operation.
  • Safe-T-Bracket® – Prevents serious injury that could occur if the bottom bracket were removed with the garage door closed and under tension.
  • Product complies with 2015 IECC air infiltration requirement of 0.40 cfm/ft2 or less (IECC, Section C402.5.2)
intellicore header
Warmer. Quieter. Stronger.
Garage doors featuring Intellicore® insulation technology represent the ultimate smart choice for homeowners. Clopay’s Intellicore® is a proprietary polyurethane foam that is injected into a garage door, expanding to fill the entire structure. The result is a door with incredible strength, energy efficiency and durability. (Click for details)



Rust-Prevention System

Paint System Rust Prevention

↑ Back To Top


Brochures

Canyon Ridge Brochure PDF

Canyon Ridge Brochure

PDF

Products available through Independent Dealers pdf

Products available through Independent Dealers

pdf

↑ Back To Top


Installation and Care

 PDF

Canyon Ridge Collection Care and Maintenance

PDF

 pdf

Handle Installation for Modern Series

pdf

 pdf

Insulated Steel Installation Instructions and Maintenance

pdf

 pdf

1 Year Installation Warranty

pdf

↑ Back To Top


Videos

VIDEOS

Canyon Ridge Modern Series Overview. Learn more about the contemporary garage door styles under the Canyon Ridge Collection, which beautifully complement mid-century and modern homes.
